SOLAR WATER HEATER - DOMESTIC
| S.NO | DESCRIPTION | Capacity |
|||
|---|---|---|---|---|---|
| 01 | No of tubes | 280 | 280 | 280 | 280 |
| 02 | Tube size | 58*1800 | 58*1800 | 58*1800 | 58*1800 |
| 03 | Tot.Floor size required(L*W*H)feet | 6.6*3.5*4 | 6.6*5*4 | 6.6*6.4*4 | 6.6*8*4 |
| 04 | Tot.Square feet(Approx) | 25 | 35 | 45 | 55 |
| 05 | Overhead tank size(Min) | 5 Feet | 5 Feet | 6 Feet | 6 Feet |
| 06 | Overhead tank size(Max) | 10 Feet | 10 Feet | 10 Feet | 10 Feet |
| 07 | Tot.System weight-without water | 35Kgs | 50Kgs | 62Kgs | 76Kgs |
| 08 | Tot.System weight-with water | 145 Feet | 215 Feet | 282 Feet | 351 Feet |
| 09 | Stand parts weight | 6 Kgs | 7.5 Kgs | 8.5 Kgs | 10 Kgs |
| 10 | Inlet/ Outlet nipple size | 3/4 inch | 3/4 inch | 1 inch | 1 inch |
| 11 | Heater nipple size | 1*1/4 inch | 1*1/4 inch | 1*1/4 inch | 1*1/4 inch |
| 12 | Heater capacity(KW) optional | 2 | 2 | 3 | 4 |
